Bathroom Door Stainless Steel Tubular Deadbolt with Plates

Code:
Z/ZTDASS-P

MATERIAL: Satin stainless steelTYPE: Bathroom Door Mortice Tubular Deadbolt with platesPLATE FINISH: Choose from powder coat black, polished stainless, brass or nickelFIXINGS: 25mm wood screws includedADDITIONAL FEATURES: Plastic dust socket comes with...Read More

Create a wishlist

"Great service great communication…"

Anthony White

Description


MATERIAL: Satin stainless steel

TYPE: Bathroom Door Mortice Tubular Deadbolt with plates

PLATE FINISH: Choose from powder coat black, polished stainless, brass or nickel

FIXINGS:
25mm wood screws included

ADDITIONAL FEATURES:
 Plastic dust socket comes with standard satin steel strike plates and forend


Description



  • Compatible with any 5mm spindle rod

  • Heavy duty bolt with bolt through fixings and a selected face plate and fore end

  • Stainless Steel deadbolt

  • Strike plates available in a powder coat black, polished stainless, brass or nickel finish to help you match with any door handle or knob

  • Available in 2.5" or 3" case lengths

  • Ideal for bathroom, toilet, WC doors where a turn and release set is required

  • Easily match with a thumb turn set

  • Meets fire FD30/FD60 standard

  • Meet BS EN 1634-1 standard






Dimensions


63mm (2.5")

Overall case size: 63mm

Backset (Edge to centre of spindle hole): 45mm

Spindle hole diameter:
5mm


76mm (3")

Overall case size: 76mm

Backset (Edge to centre of spindle hole): 57mm

Spindle hole diameter: 5mm



Strike plate dimensions:


Strike plate length:
 60mm

Strike plate largest width:
 25mm

Dimensions

Size 2.5" (64mm)
3" (76mm)

Details

Plate Finish Nickel
Polished Stainless
Powder Coated Black
Brass
